Anti-Theft Display Cable
DE30MSC
A compact square base with an integrated external spring cable, a 360° swivel and screw-locked host-to-alarm connections. DE30MSC holds phones and tablets in PJ022 claw mounts and triggers a ≥90 dB alarm on touch, plug-out, cable-cut or power unplug.
Key facts
- Input5V/2A
- Output5V 1.5–2A
- Matching cableLCS087-1C / L / 1M / 1FM
- Length600 mm
- ClawsPJ022A–D
- Alarm≥90 dB
- DevicesPhones · Tablets
Why retailers choose it
- Square 56.17 × 49.42 mm footprint keeps a tight counter line; the external spring cable stretches without tangling.
- Host and alarm line connect with screws, and the desk lockdown adds a screw iron plate, 3M adhesive and butterfly nut.
- Built-in retractable steel cable above 90 lb tensile with a recoiler rated past 30,000 pulls.
- Four alarm triggers — touch, plug-out, cable-cut, power unplug — at ≥90 dB, decoded with one 2.4G key.
- Claw mounts PJ022A–D secure phones and tablets with two or four contact points per device.
Full specifications
Datasheet
Every value below comes from the DE30MSC datasheet. The claw-grip layout suits counters where devices need to be lifted, flipped and returned.
| Model | DE30MSC |
| Input | 5V/2A |
| Output | 5V 1.5–2A |
| Matching cable | LCS087-1C / LCS087-L / LCS087-1M / LCS087-1FM |
| Length | 600 mm |
| Power adapter | 5V/2A |
| Claw options | PJ022A (two claws, phone) · PJ022B (four claws, phone) · PJ022C (two claws, tablet) · PJ022D (four claws, tablet) |
| Material | ABS + zinc alloy |
| Alarm methods | Touch point / plug-out / cable-cut / power unplug |
| Decoding method | 2.4G |
| Standby time | 24 h |
| Alarm sound | ≥90 dB |
| Dimensions | 56.17 × 49.42 × 122.59 mm |
| Application | Retail counters: phones, tablets |
Phone retail
Two- and four-claw PJ022 mounts keep phones reachable while the host stays hidden under the counter.
Brand stores
The square low-profile base and external spring cable hide the security hardware between display fixtures.
Mall counters
Screw iron plate plus 3M and butterfly nut hold the stand through high-traffic lifts at demo tables.
How the alarm responds
- Touch point detection on the claw and device contacts.
- Plug-out alarm when the device is lifted off the socket.
- Cable-cut alarm on a severed sensor line.
- Power-unplug alarm if the 5V/2A adapter is disconnected.
- 2.4G key decode silences and resets each lane.
Built for the demo counter
- 360° swivel with a 15° optimal viewing angle.
- Internal snap-fit charging port.
- Modular design for easy claw and part replacement.
- Optional metal claws as an extra theft deterrent.
- Replaceable retractable cable with quick charge.
Also in this family
Same rail, different reach.
Same 5V/2A rail, same LCS087 cable family — the DE30MSC is the square-design claw-grip member of the family.
| Model | Input | Output | Cable | Length | Standby |
|---|---|---|---|---|---|
| DE30MLA | 5V/2A | 5V 1.5–2A | LCS087-1C / 1L / 1M / 1FM | 600 mm | 24 h |
| DE30MSA | 5V/2A | 5V 1.5–2A | LCS087-1C / LCS087-L / 1M / 1FM | 600 mm | 24 h |
| DE30MSC | 5V/2A | 5V 1.5–2A | LCS087-1C / LCS087-L / 1M / 1FM | 600 mm | 24 h |
| DE50MLA | 5V/2A | 5V 1.5–2A | LCS087-1C / 1L / 1M / 1FM | 680 mm | 12 h |
| DE50MSA | 5V/2A | 5V 1.5–2A | LCS087-1C / LCS087-L / 1M / 1FM | 680 mm | 12 h |
